MicroScribe® MX 系列

MicroScribe® MX
Building on the G2 technology, Immersion have broken the mould with the new MX & MLX arms that offer metrology level accuracy.

MicroScribe® Spinning Stylus
Each of the MicroScribe G2's and MX's are available as built to order systems with a 6th degree of freedom around the stylus. The standard spinning stylus includes a rotary encoder and has the option to add a transducer mount for fixing of other equipment. The spinning stylus models are normally only purchased for special applications where the user is developing their own attachments and specialised software.

　　

Standard Spinning Stylus　　　　　　　Spinning Stylus with optional transducer mount

NEW ! MicroScribe® MX Now available !

MicroScribe MX systems offer metrology level accuracy, an easy-to-use articulated arm design, and seamless integration with the most popular reverse engineering and metrology software packages.

The MicroScribe system supplies a new, more cost-effective alternative for manufactured parts inspection, reverse engineering, and high-accuracy 3D digitizing

Immersion qualifies the MicroScribe MX systems' high accuracy using its Tri-Test Calibration(TM) Method. This test methodology aligns to the American Society of Mechanical Engineers' B89.4.22 draft specification for evaluating performance of articulated arm coordinate measurement machines (CMMs).
  • Flexible articulated arm technology
  • Metrology-level accuracy (+/- 0.114mm)
  • Portable and easy to use (less than 4Kg)
  • 2 Ruby ball 3mm tips included
  • USB 2.0 connectivity
  • Third party software compatible
  • Available in 2 models MX and MLX
  • Delivery times are estimated to be around 7 to 10 days for the MX arms.

 　
機型

Model

Accuracy

Workspace

MicroScribe-G2

0.38mm

1270mm 球體

MicroScribe-G2X

0.23mm

1270mm 球體

MicroScribe-G2L

0.43mm

1675mm 球體

MicroScribe-G2LX

0.30mm

1675mm 球體

　

　

MicroScribe-G2 Spinning Stylus

0.38mm

1270mm 球體

MicroScribe-G2X Spinning Stylus

0.23mm

1270mm 球體

MicroScribe-G2L Spinning Stylus

0.43mm

1675mm 球體

MicroScribe-G2LX Spinning Stylus

0.30mm

1675mm 球體

　

　

MicroScribe-MX

+/- 0.114mm

1270mm 球體

MicroScribe-MLX

+/- 0.152mm

1675mm 球體

　

　

MicroScribe-MX Spinning Stylus

+/- 0.114mm

1270mm 球體

MicroScribe-MLX Spinning Stylus

+/- 0.152mm

1675mm 球體

　
MicroScribe G2 可搭配軟體

 CAD/CAM

Host Application

Host Manufacturer

Support

3rd Plug-in Support

　

Alias StudioTools

Alias|Wavefront



PC

AlphaCAM

Licom



PC

AutoCAD

Autodesk

HighRES BASIC
HighRES ADVANCED
HighRES INDUSTRIAL
HighRES Feature PLUS 1
HighRES Feature PLUS 2

PC

AutoCAD Mechanical

Autodesk

HighRES BASIC
HighRES ADVANCED
HighRES INDUSTRIAL
HighRES Feature PLUS 1
HighRES Feature PLUS 2

PC

Autodesk VIZ

Autodesk



Scribe-iT Power Digitizer Pack

PC

CADKEY

CADKEY Corporation



HighRES BASIC
HighRES ADVANCED
HighRES INDUSTRIAL
HighRES Feature PLUS 1
HighRES Feature PLUS 2
RevEng
SurfINSPECT

PC

HandyCut

PicaSoft



　

　

HandyScan

PicaSoft



　

PC

Inventor

Autodesk

HighRES ADVANCED
HighRES INDUSTRIAL
HighRES Feature PLUS 1
HighRES Feature PLUS 2

PC

PowerINSPECT

Delcam



PC

PowerSHAPE

Delcam



PC

Mayka

ProSoft SA



PC/MAC

Mastercam

Mastercam

HighRES BASIC
HighRES ADVANCED
HighRES INDUSTRIAL
HighRES Feature PLUS 1
HighRES Feature PLUS 2
Verisurf

PC

Mechanical Desktop

Autodesk

HighRES BASIC
HighRES ADVANCED
HighRES INDUSTRIAL
HighRES Feature PLUS 1
HighRES Feature PLUS 2

PC

Metrix Build!IT

MAYA Metrix

　

PC

Pro/ENGINEER

PTC

HighRES ADVANCED
HighRES INDUSTRIAL
HighRES Feature PLUS 1
HighRES Feature PLUS 2

PC

Rhinoceros (Rhino3D)

MicroScribe Tutorial
available.

Robert McNeel & Associates



PC

Shoemaster

CSM3D International Limited



PC

SolidThinking

EVOQE s.r.l.



　

PC/MAC

SolidWorks

SolidWorks Corp.



DezignWorks
HighRES BASIC
HighRES ADVANCED
HighRES INDUSTRIAL
HighRES Feature PLUS 1
HighRES Feature PLUS 2
REVWARE REVWORKS

PC

SURFCAM

Surfware, Inc.



PC

3D 美工/影像

Host Application

Host Manufacturer

Support

Plug-in Suport

　

3ds max

Discreet



Scribe-iT
Power Digitizer Pack

PC

Autodesk VIZ

Autodesk



Scribe-iT
Power Digitizer Pack

PC

form·Z

auto·des·sys, Inc.



PC/MAC

LightWave 3D

NewTek



DigiScribe

PC

Maya

Alias|Wavefront



MicroScribe Connections

PC/MAC

Rhinoceros

Robert McNeel & Associates



　

PC

PiXELS 3D

PiXELS Digital, Inc.



MAC

solidThinking

EVOQE s.r.l.



　

PC/MAC

Softimage | XSI

Softimage



PC

Amapi 3D

ENOVIA



PC/MAC

選配附件


Support Tripod Hand Switch Rugged Carrying Case
Double Digital Foot Pedal Universal Power Supply Digitizing Fixture Plate
Standard Tip Ball Tip Extra Fine Tip
